E-Forza 100” News!

Yes, finally the very popular Forza 100 is available with an E-Fuselage. Note this is not quick re-hash. I have re- designed and made new moulds for this new E-Model with slightly modified curves so as to allow for a wide range of batteries and motors - but it still looks good! Note that the rudder and elevator servos are now mounted in the fin to give more room for motor and battery. The spinner diameter is 34mm. Talk to your friendly neighborhood Aeroic dealer!

Every Aeroic model comes (S) standard 100% single carbon wing, and carbon tissue surface laminated tail planes.

Light and SS (double carbon) versions are available build to order.

Models general layups information:

Light – Mostly glass fibre layup with carbon tissue wings and tailplanes with some carbon and Kevlar reinforcement.

S – Single carbon wing and fuselage with carbon tissue tailplanes, Kevlar fuselage front (2.4 GHz friendly).

SS – Double carbon wing and carbon fuselage and double ASWS with carbon tissue tailplanes, Kevlar fuselage front (2.4 GHz friendly).

Forza 100” (2.5M)

Forza 100 Basic information:

Mid-sized slope allrounder. Like all Aeroic models this one is good looking, fast and very aerobatic. Super rigid wings with OLP (Optimised lift planform) and special high-response aerofoil sections with the HSWS give it a huge flight envelope. Elevator and rudder servos are easily mounted in the fin and accessed via a convenient moulded-in hatch. With its transportability and sparkling performance, the Forza has become many slope flyers’ weapon of choice.

Construction: GFK/CFK Hybrid (Aeroic)
Wings: Carbon with Aeroic Sine Wave Spar
Fuse: Strong Carbon/Kevlar Reinforced Glass (2.4Ghz friendly)

Forza 100 Specifications:

Span:                                                               100” (2.5M)

Length:                                                            48.5” (1.23M)

Wing area:                                                       723.3Sq” (46.66dm)

Wing aerofoils:                                                JH3680, JH3675, JH3670

Tailplane aerofoils:                                         JH10SYM

Ballast (Wings)                                                750g (26.5oz)

Controls:                                                         Ailerons, Flaps, Elevator, Rudder

Designer:                                                         Dr. James D. Hammond

E-Forza 100

Electric version of the Forza with a slightly enlarged fuselage, top canopy and round nose exit to accommodate a spinner. All other details are the same as the glider version.

Note the extensive hardware package included in every Aeroic kit. The Forza kit includes: Fuselage ballast tube, pre-wired servo harness that matches molded in fuse and wing pockets, elevator and rudder servo extensions, linkage set including elevator ball link, aileron and flap pushrods with quality metal clevis’, servo frames, color matched control horn covers, both hollow and solid carbon tail spars, color matched flat and bump wing servo covers & tail closeout cover.
